Wall & Roof Sheeting Identification Guide

Do you own an old steel shed and have no idea which type of cladding you currently use?

Lucky for you, we’ve created a detailed guide that will help you figure out the specific type of wall and roof cladding for your next remodelling project.

Once you’ve identified the cladding on your own within minutes, it will open up so many opportunities to you. Not only will you know what to look for when you need to replace any panels, but you’ll know the exact profile vermin proofing suitable for your needs.

Hint: If you take a photo/measurements of your shed and compare it to the data in the Wall & Roof Sheeting Identification Guide below you’ll identify it much quicker.

Lysaght

lysaght custom orb size
lysaght custom orb profile
Custom Orb

  • Used on roofs and walls
  • COLORBOND® or Zincalume
  • Variations – ultra, perforated, gloss

lysaght multiclad size
lysaght multiclad profile
Multiclad

  • Used on walls only
  • COLORBOND® or Zincalume
  • 2 thicknesses

lysaght mini orb size
lysaght mini orb profile
Mini Orb

  • Used on roofs and walls
  • Corrugations run vertically or horizontally
  • Can be used for curved and flat installations

lysaght panelrib size
lysaght panelrib profile
Panelrib

  • Used for eaves on buildings
  • Flat or curved
  • Flutes run horizontally or vertically

lysaght spandek size
lysaght spandek profile
Spandek

  • Can be used for both roofing and walling applications
  • Available in a wide variety of COLORBOND® steel colours
  • Allows wide support spacings

lysaght trimdek size
lysaght trimdek profile
Trimdek

  • Used for roofs and walls
  • Allows wide support spacing
  • Ideal for all types of buildings

lysaght wallclad size
lysaght wallclad profile
Wallclad

  • Lightweight walling profile
  • Wide range of colours
  • Corrugations run vertically or horizontally

lysaght trimwall size
lysaght trimwall profile
Trimwall

  • Used for domestic buildings
  • Easy to install lightweight walling profile
  • Wide range of colours

Stramit

stramit corrugated size
stramit corrugated profile
Corrugated

  • High tensile, light weight roof and wall cladding
  • Conventional through fixed screws
  • Available in G300 steel

stramit monoclad size
stramit monoclad profile
Monoclad

  • Installation through fixing and notching of flashings
  • Features include deep ribs, domed crest, anti-capillary side laps
  • Lightweight and weather resistance cladding

stramit kpanel size
stramit kpanel profile
K-Panel

  • Fixing through fixed screws
  • Low rib height
  • Cold roll formed steel wall sheeting used for sheds and light industrial buildings

stramit longspan size
stramit longspan profile
Longspan

  • Long spanning high strength roof and wall sheet
  • Used for commercial roofing and walling applications
  • Available in long lengths

stramit mini corry size
stramit mini corry profile
Mini Corry

  • Small scale version of normal corrugated profile
  • Used only for walling applications (not suitable for roofing)
  • Consistent profile and longer lengths, made of high tensile material

Fielders

fielders tl-5 size
fielders tl-5 profile
TL-5

  • Used for wall panelling, cladding and short span roofing
  • Rib height 28mm, large sheet coverage 760mm
  • Uses specially designed capillary grooves for complete watertightness

fielders lo-rib size
fielders lo-rib profile
Lo-Rib

  • Used for wall cladding in steel buildings or sheds
  • Available in Zincalume® and Colorbond®
  • High tensile steel in both 0.35mm and 0.24mm based metal thickness

fielders s-rib corrugated size
fielders s-rib corrugated profile
S-Rib Corrugated

  • Corrugated roofing and walling finish
  • Available in standard corrugated or Barrel Rolled, S-Rib™
  • Uses heavy coated Galvanised Z600 steel

Titan Sheds

Details not supplied by Titan but is dimensionally similar to Monoclad. Sheet is 830mm wide with 762mm effective cover
titansheds qdek profile
Qdek

  • Manufactured at Titan
  • QDEK metal wall or Roof sheeting
  • In standard straight-cut lengths

Details not supplied by Titan but is dimensionally similar to K-Panel. Sheet 890mm wide with 862mm effective cover
titansheds vdek profile
Vdek

  • Manufactured at Titan Garages, Crestmead Qld
  • VDEK metal wall or facia sheeting
  • In standard straight-cut lengths

Stratco

stratco cgi corrugated size
stratco cgi corrugated profile
CGI Corrugated

  • Used as a roofing, walling and fencing material
  • Available in long lengths and a range of thicknesses
  • Available in long lengths for added life and enhanced appearance

stratco maxirib size
stratco maxirib profile
Maxirib

  • Designed for wall cladding applications
  • Use on ceilings, walling, fascias and barge boards
  • Available in a full spectrum of colours or un-painted zinc/al

stratco superdek size
stratco superdek profile
Superdek

  • High tensile strength and features a trapezoidal shape
  • Used for domestic roofing, walling and fencing applications
  • 28mm rib height that allows for long spans

Totalspan

totalspan 7-rib 035 size
totalspan 7-rib 035 profile
7-Rib, 0.35BMT

  • Seven rib cladding profile

totalspan 7-rib 042 size
totalspan 7-rib 042 profile
7-Rib, 0.42BMT

  • Seven rib cladding profile

totalspan corrugated size
totalspan corrugated profile

Metroll

metroll trimclad size
metroll trimclad profile
Trimclad

  • Used to clad and roof industrial buildings, homes, carports or patios
  • Manufactured from .42mm and .48mm B.M.T. Colorbond® and Zincalume® or Galvanized® steel.
  • Sheeting up to a maximum length of 35 meters can be supplied

metroll metroclad size
metroll metroclad profile
Metroclad

  • Low rib height, custom length, high tensile steel wall cladding only profile
  • Manufactured from .35mm and .42 B.M.T. Colorbond® and Zincalume®
  • Overall width of 880mm wide with a cover width of 850mm, 214mm pan x 13mm rib height

metroll corodek size
metroll corodek profile
Corodek

  • Used as roofing and cladding and internal walling, ceilings and facades.
  • Corrugated roofing and wall cladding manufactured from .42mm and .48mm B.M.T. Colorbond® and Zincalume®
  • Sheeting up to a maximum length of 15 meters can be supplied
